• This Mikrotik small home access point is the perfect device for homes or small offices where all you need is a wireless AP and a few wired devices connected. Based on our popular RB951-2n, the new hAP is an improvement in many areas.
• The Mikrotik device can be powered from the power jack or with passive PoE from a PoE injector. The power adapter is included.
• Mikrotik hAP provides PoE output function for port #5 - it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
• The Mikrotik hAP is preconfigured, so all you need to do, is plug in the internet cable, the power, and start using the internet by connecting to the MikroTik network.
• Mikrotik Dual chain wireless 2.4GHz / 650MHz CPU / 64MB of RAM / Passive PoE output on port 5 / USB port for 3G/4G modem.

説明: SKU:?RB951Ui-2nD

Mikrotik RouterBoard RB951Ui-2nD hAP homes or offices 2.4GHz Access Point 5-ports PoE OSL4 USB for 3G/4G

This small home access point is the perfect device for homes or small offices where all you need is a wireless AP and a few wired devices connected. Based on our popular RB951-2n, the new hAP is an improvement in many areas.

The device can be powered from the power jack or with passive PoE from a PoE injector. The power adapter is included.

hAP provides PoE output function for port #5 - it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.

The hAP is preconfigured, so all you need to do, is plug in the internet cable, the power, and start using the internet by connecting to the MikroTik network.

Technical Description

Architecture?? ?MIPSBE
CPU?? ?QCA9531
CPU core count?? ?1
CPU nominal frequency?? ?650 MHz
Dimensions?? ?113 x 89 x 28mm
License level?? ?4
Operating System?? ?RouterOS
Size of RAM?? ?64 MB
Storage size?? ?16 MB
Storage type?? ?FLASH
Tested ambient temperature?? ?-30°C to 70°C
PoE in?? ?Passive PoE
PoE in input Voltage?? ?10-28 V
PoE out?? ?Passive PoE
PoE-out ports?? ?Ether5
Number of DC inputs?? ?2 (DC jack, PoE-IN)
DC jack input Voltage?? ?10-28 V
Max out per port output (input lt; 30 V)?? ?500 mA Max power consumption?? ?5 W
Wireless 2.4 GHz Max data rate?? ?300 Mbit/s
Wireless 2.4 GHz number of chains?? ?2
Wireless 2.4 GHz standards?? ?802.11b/g/n
Antenna gain dBi for 2.4 GHz?? ?1.5
Wireless 2.4 GHz chip model?? ?QCA9531
Wireless 2.4 GHz generation?? ?Wi-Fi 4
10/100 Ethernet ports?? ? 5
Number of USB ports?? ? 1
USB Power Reset?? ?Yes
USB slot type?? ?USB type A
Max USB current (A)?? ?1
Certification?? ?CE/RED, FCC, IC, EAC, ROHS

カテゴリー: ルーター
メーカー: Mikrotik
ブランド: MikroTik
高さ: 17.5 センチ
幅: 12.0 センチ
奥行: 4.8 センチ
重量: 0.3 Kg
